マルチカントシステムを採用し、センターボルトを外すだけで幅広いセッティングが可能なALCバインディング。
2024-2025モデルの「ALC BINDING 64」からはクリップがアルミ製から樹脂製に変更となりました。
1.マルチカントシステムにより0°~8°まで10段階でカントリングの角度調整が可能
・合わせたカントリングを10°きざみで回転できます。
2.付属の六角レンチを使用してセンターボルトを外すだけでカント調整が可能
・ネジや、部品を持ち歩く必要がありません。
3.金属部品、樹脂部品をバランス良く採用。硬すぎず柔らかすぎないフレックス
・ベイルは6mmの太軸を採用。
・メインのアッパープレートは、5mm厚の超々ジュラルミンを切削加工。
・ベースプレート、カントリングには、ABS樹脂を採用。
4.プレートを使用する場合は別売の薄型ベースプレートを使用可能
・使用により標準プレートよりも高さを5mm低くすることが出来ると共に軽量化が可能。
5.23-24モデルからヒールブロックでも微調整が可能に
・これまでの最小調整幅が3.3mmから1.5mmに。トゥ側に加えヒール側にも機構を採用。
・それによりブロック固定ビスはトゥ側もヒール側も共通になりました(バインドM6×14mm)。
・ヒールブロックのベイルがあたる部分に角度がつき、グローブやウェアなどが引っ掛かりやすくなっております。
生地の破れが無いよう、また、メンテナンス中に小さなお子様が触れないようご注意ください。
The ALC Binding features a Multi-Cant System that allows for a wide range of stance adjustments simply by removing the center bolt.
Starting with the 2024–2025 model “ALC BINDING 64,” the clip has been changed from aluminum to resin.
1. The Multi-Cant System enables canting angle adjustment in 10 steps from 0°to 8°
・Matched cant rings can be rotated in 10° increments.
2. Cant angle can be adjusted by simply removing the center bolt using the included hex wrench
・There is no need to carry screws or additional parts.
3. A balanced use of metal and resin components provides flex that is neither too stiff nor too soft
・The bail features a thick 6mm diameter.
・The main upper plate is CNC machined from 5mm thick extra-hardened alminum alloy.
・The base plate and cant rings are made from ABS resin.
4. When using plates, the optional low-profile base plate can be used
・This reduces height by 5mm compared to the standard plate and also contributes to weight savings.
5. From the 2023–2024 model, fine adjustments are now possible on the heel block as well
・The minimum adjustment range has been reduced from 3.3mm to 1.5mm. The same mechanism used on the toe side is now applied to the heel side.
・As a result, the block fixing screws are now standardized for both toe and heel sides (Binding M6×14mm).
・The contact point of the bail on the heel block is now angled, making it easier for gloves or clothing to catch.
Please take care to avoid fabric damage and ensure small children do not touch it during maintenance.
The English version of the manual can be downloaded
HERE(Coming soon) .
